STX2496
DESCRIPTION
TECHNICAL SPECIFICATIONS
CHARACTERISTICS | STX2496 |
---|---|
Number of processors (DSPs) | 2 |
Input Channels | 2 |
Output Channels | 6 |
Master Level | 0 ~ 100% |
Graphic Equalizer | 15 Bandas (Band) |
Parametric Equalizer Output | 5 / Saída (Total: 30) |
Routing | A,B / A+B |
Crossover Bessel (dB/8ª) | 12/18/24 |
Crossover Butterworth (dB/8ª) | 6/12/18/24/36/48 |
Crossover Linkwitz-Riley (dB/8ª) | 12/18/24/36/48 |
Limiter | ✔ |
Automatic Attack/Release | ✔ |
Manual Attack/Release | ✔ |
Delay | 0 ~ 8ms (275cm) |
Display | OLEAD Gráfico/Graphic 3.12" |
Screen saver | Animações/Animations |
Security Password | ✔ |
Frequency Response | 10Hz ~ 22,5KHz @ -1 dB |
Latency | 1,08 ms |
Signal to Noise | >90 dB |
THD | <0,01% |
Channel Separation | >80 dB |
Maximum Input Voltage | 5,6 Vpp (+8,2 dBu) |
Maximum Output Voltage | 5,6 Vpp (+8,2 dBu) |
Supply Voltage | 10V ~ 15V DC |
Auxiliary Supply Voltage | 12Vdc + Botão/Button ON/OFF |
Dimensions (H x W x D) mm | 37 x 204 x 151 mm |
Weight Kg | 0.560 |
