New EX21000 EQ – 1 Ohm from EXPORT LINE, the line of automotive amplifiers developed to delight Brazil and the World.
The New EX21000 EQ is an Amplifier for fans of #SomAutomotive or for competition lovers!
Designed for those looking for high performance and sound fidelity, this EX Line product brings the proven EQ Technology allowing individual equalization for the bands: Bass, Mid Bass and Mid High in addition to the traditional Level, High Pass and Low Pass
Frequency response from 10Hz to 10KHz
With more than 80% efficiency, the EX Line amplifiers are very economical, allowing the user to keep the sound playing longer.
It has the Over Clip feature that provides an additional 15% of final power before indicating the distortion through the Led Clip.
|CHARACTERISTICS||EX 21000 EQ – 1 OHM|
|Number of Channels||1|
|RMS Power at 1 Ohm 12.6V||21.000W RMS|
|RMS Power at 2 Ohm 12.6V||12.800W RMS|
|RMS Power at 4 Ohm 12.6V||8.000W RMS|
|RMS Power at 1 Ohm 14.4V||23.000W RMS|
|RMS Power at 2 Ohm 14.4V||14.200W RMS|
|RMS Power at 4 Ohm 14.4V||9.000W RMS|
|Frequency Response||10Hz ~ 10 KHz|
|Crossover Low Pass||10Hz ~ 10 KHz|
|Crossover High Pass||50Hz ~ 700 KHz|
|Signal to Noise||>90dB|
|Harmonic Distortion||< 0,9% THD|
|Input Impedance||25K OHMS|
|Impedance Output||1 OHM|
|Consumption with Signal Musical||5,8 ~ 990A|
|Consumption with Signal Bass||5,8 ~ 1980A|
|Dimensions (H x W x D) mm||77 x 294 x 614 mm|
|Weight Kg||9,8 Kg|
TIPS HOW THE EX 21000 EQ – 1 OHM
FROM STETSOM CAN BE INSTALLED
